JAN Equivalent
For designs requiring military/JAN qualification, these parts are cross-mapped to their JAN-standard equivalents with full traceability.
Our JAN-equivalent parts are manufactured to MIL-S-19500 standards, ensuring enhanced durability and consistency. Each part undergoes stringent testing and quality assurance processes to deliver superior performance in the most demanding environments. Whether you need components for defense systems, aerospace technology, or other high-reliability applications, our JAN-equivalent JFETs provide a dependable solution. Custom solutions available.
An abstract image of satellite in extreme environment
| PRODUCT | PACKAGE | BVgss (min) V | Vgso (min) V | Vgso (max) V | Idss (min) mA | Idss (max) mA | Gm (min) mS | ēn (typ) ɳV√Hz | Ciss (max) pF | TYPE | CONFIG | ORDERING |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PRODUCT | PACKAGE | BVgss (min) V | Vgso (min) V | Vgso (max) V | Idss (min) mA | Idss (max) mA | Gm (min) mS | ēn (typ) ɳV√Hz | Ciss (max) pF | TYPE | CONFIG | ORDERING |
| 2N2608JAN | TO-18 | 30 | 1.00 | 4.00 | -0.90 | -4.50 | 1.00 | 10.00 | 17.00 | P-CH | SINGLE | Direct |
| 2N2609JAN | TO-18 | 30 | 0.75 | 6.00 | -2.00 | -10.00 | 2.00 | 10.00 | 30.00 | P-CH | SINGLE | Direct |
| 2N3821JAN | TO-72 | -50 | -0.50 | -4.00 | 0.50 | 2.50 | 1.50 | 7.00 | 6.00 | N-CH | SINGLE | Direct |
| 2N3822JAN | TO-72 | -50 | -0.50 | -6.00 | 2.00 | 10.00 | 3.00 | 7.00 | 6.00 | N-CH | SINGLE | Direct |
| 2N4091JAN | TO-18 | -40 | -4.00 | -10.00 | 30.00 | 1.20 | 16.00 | N-CH | SINGLE | Direct | ||
| 2N4092JAN | TO-18 | -40 | -2.40 | -3.20 | 15.00 | 1.20 | 16.00 | N-CH | SINGLE | Direct | ||
| 2N4093JAN | TO-18 | -40 | -1.00 | -5.00 | 8.00 | 1.20 | 16.00 | N-CH | SINGLE | Direct | ||
| 2N4117AJAN | TO-72 | -40 | -0.60 | -1.80 | 0.03 | 0.09 | 0.07 | 8.00 | 3.00 | N-CH | SINGLE | Direct |
| 2N4117JAN | TO-72 | -40 | -0.60 | -1.80 | 0.03 | 0.09 | 0.07 | 8.00 | 3.00 | N-CH | SINGLE | Direct |
| 2N4118AJAN | TO-72 | -40 | -1.00 | -3.00 | 0.08 | 0.24 | 0.08 | 8.00 | 3.00 | N-CH | SINGLE | Direct |
| 2N4118JAN | TO-72 | -40 | -1.00 | -3.00 | 0.08 | 0.24 | 0.08 | 8.00 | 3.00 | N-CH | SINGLE | Direct |
| 2N4119AJAN | TO-72 | -40 | -2.00 | -6.00 | 0.20 | 0.60 | 0.10 | 8.00 | 3.00 | N-CH | SINGLE | Direct |
| 2N4119JAN | TO-72 | -40 | -2.00 | -6.00 | 0.20 | 0.60 | 0.10 | 8.00 | 3.00 | N-CH | SINGLE | Direct |
| 2N4338JAN | TO-18 | -50 | -0.30 | -1.00 | 0.20 | 0.60 | 0.60 | 6.00 | 7.00 | N-CH | SINGLE | Direct |
| 2N4339JAN | TO-18 | -50 | -0.60 | -1.80 | 0.50 | 1.50 | 0.80 | 6.00 | 7.00 | N-CH | SINGLE | Direct |
| 2N4391JAN | TO-18 | -40 | -4.00 | -10.00 | 50.00 | 150.00 | 1.20 | 14.00 | N-CH | SINGLE | Direct | |
| 2N4392JAN | TO-18 | -40 | -2.00 | -5.00 | 25.00 | 75.00 | 1.20 | 14.00 | N-CH | SINGLE | Direct | |
| 2N4393JAN | TO-18 | -40 | -0.50 | -3.00 | 5.00 | 30.00 | 1.20 | 14.00 | N-CH | SINGLE | Direct | |
| 2N4856AJAN | TO-18 | -40 | -4.00 | -10.00 | 50.00 | 1.20 | 10.00 | N-CH | SINGLE | Direct | ||
| 2N4856JAN | TO-18 | -40 | -4.00 | -10.00 | 50.00 | 1.20 | 18.00 | N-CH | SINGLE | Direct | ||
| 2N4857AJAN | TO-18 | -40 | -2.00 | -6.00 | 20.00 | 100.00 | 1.20 | 10.00 | N-CH | SINGLE | Direct | |
| 2N4857JAN | TO-18 | -40 | -2.00 | -6.00 | 20.00 | 100.00 | 1.20 | 18.00 | N-CH | SINGLE | Direct | |
| 2N4858AJAN | TO-18 | -40 | -0.80 | -4.00 | 8.00 | 80.00 | 1.20 | 10.00 | N-CH | SINGLE | Direct | |
| 2N4858JAN | TO-18 | -40 | -0.80 | -4.00 | 8.00 | 80.00 | 1.20 | 18.00 | N-CH | SINGLE | Direct | |
| 2N4859AJAN | TO-18 | -30 | -4.00 | -10.00 | 50.00 | 1.20 | 10.00 | N-CH | SINGLE | Direct |
